Illustrated Factory Service Training (Workshop) Manual for Linde Pallet Truck Type 035.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
L10AC
L12AC
L16AC

Format: PDF, 56 Pages
Language: English

Contents:

6 Electrical equipment
6.1 Presentation of the CURTIS 1207A controller
6.1.1 Description of the CURTIS controller
6.1.2 Pallet truck operation
6.1.3 Operating principle
6.1.3.1 Forward movement
6.1.3.2 Reverse movement
6.1.3.3 Free wheel circuit
6.1.3.4 Counter current braking
6.1.4 Electrical components
6.1.5 Power unit connections
6.1.5.1 Pin connections 1X1
6.1.6 Switching on the pallet truck
6.1.7 Contactor power supply
6.1.8 Selecting a direction
6.1.9 Accelerator
6.1.10 Driver safety microswitch 1S3
6.1.11 Traction speed reduction option
6.1.12 Electric brake control
6.1.13 Temperature sensors
6.1.14 Line contactor (option)
6.2 Diagnostics
6.2.1 Starting up the software
6.2.2 Main window
6.2.3 Opening page
6.2.4 Programming menu
6.2.5 Saving parameters
6.2.6 Test menu
6.2.7 Diagnostic menu
6.2.8 Diagnostic without computer
6.2.9 Electrical diagram
6.2.10 Pin Connections connector 1X1
6.3 Electrical steering LPS-2
6.3.1 Connector 3X1 pin connections
6.3.2 Connector 3X2 pin connections
6.3.3 Switch on steering
6.3.4 Activating the steering
6.3.5 Calibration resistance
6.3.6 Adjusting the electrical steering
6.3.7 Steering faults
6.3.7.1 General
6.3.7.2 Test points on the control board
6.3.7.3 Specification
6.3.7.4 What to do when ...

---
